ALP-301

ALP-451

ALP-681

Part Number

30:1

45:1

68:1

Pressure Ratio

3-7 BAR

3-7 BAR

3-7 BAR

Operating Pressure

11.8 LITER/MIN

15LITER/MIN

10.8 LITER/MIN

Max. Deliver

195 BAR(2800 PSI)

320BAR(4600PSI)

480 BAR(7000PSI)

Max. Discharge Pressure

90 95 DB

90-95 DP

90-95 DP

Noise Level

120MM

120MM

120 MM

Air Motor Stroke

3/4 INCH

3/4 INCH

3.4 INCH

Air Inlet Size

3/4 INCH

1 INCH

1 INCH

Fluid Inlet Size

1/4, 3/8 INCH

1/4,3/8 INCH

1/4, 3/8 INCH

Fluid Outlet Size

60KG

93 KG

93 KG

Weight

253.8

253.8

253.8

Cylinder Diameter

Shipyards, Construction, Container Coating

Application

Epoxy Primers, Alkyd, Urethane, high Viscosity Materials

Typical Fluid Handled
